1. 主要参数..
Main product specification
|
最大输出功率
Max.output power |
输入电压
Input voltage |
最高输出电压
Output voltage |
误差范围
Combined regulation |
输出电流
Output current |
误差范围Combined
regulation |
|
900W |
230Vac |
29.4V+/-0.2Vdc |
+/-0.2V |
25A |
+/-0.2A |
2.输入特征：
Input characteristic
|
序号No. |
项目Item
|
技术参数 Technical specification
|
备注 Remark
|
|
1 |
额定输入电压
Rated input voltage |
230Vac |
230Vac |
|
2 |
电压输入范围
Input voltage range |
180 ~ 240Vac |
|
3 |
频率
AC input voltage frequency |
50～60 Hz |
3. 输出特征和充电模式：
Output characteristic or charge stages
|
序号
No. |
项目
Item |
技术参数
Technical specification |
备注
Remark |
|
1 |
恒流
CC(constant current) |
≤29.4Vdc, 25A |
|
|
2 |
恒压
CV(constant voltage) |
29.4Vdc, 25A↓ |
|
|
3 |
浮充 Float stage |
27.6 Vdc, 4→0A |
20%CC |
|
4 |
效率
Power efficiency |
≥90% |
输入电压=230Vac, 额定负载
Vin=230Vac,rated load |
4.充电指示
Charging indicator
|
序号No. |
项目 Item |
状态 Status |
备注Remark |
|
1 |
电源Power on |
LED1: 红灯 Red |
|
|
2 |
充电Charging |
LED2: 红灯 Red |
|
|
3 |
充满 Fully charged |
LED2: 绿灯 Green |
|
|
4 |
输出电压显示
Charging Voltage Display |
否 No
|
|
|
5 |
输出电流显示
Charging Current Display |
否 No
|
|
